Dimensions
Width: 29.94" (76.0 cm)Height: 47.38" (120.3 cm)Depth: 28.5" (72.4 cm)
Shipping Dimensions
Width: 30.75" (78.1 cm)Height: 49.5" (125.7 cm)Depth: 30.25" (76.8 cm)
Weight
224.00 lbs (101.6 kg))
Key Features
- Even-Heat True Convection
- 6.7 Cu. Ft. Total Capacity
- 5 Cooking Elements Including a Warm Zone
- Triple-Ring Element
- Hidden Bake
Even-Heat True Convection
The unique bow-tie design and convection fan ensure the inside of the entire oven is heated to, and stays at, the perfect temperature. That's a recipe for flawless results.
6.7 Cu. Ft. Total Capacity
Get an extra-large combined cooking capacity for preparing multiple dishes at once and enjoy the flexibility of separate temperature zones.
5 Cooking Elements Including a Warm Zone
Five independent cooking surfaces allows you to do more on your range. This range features a triple cooking zone of 6, 9 and 12 inches, one 10-inch zone and two 6-inch cooking zones, plus a dedicated warming zone.
Triple-Ring Element
With three element sizes at one location, you get the versatility to match cooking surface to cookware size.
Hidden Bake
Wipe away spills with eases thanks to this handy feature which covers up the baking element.
Full Features and Specifications
Additional Key Features:
- Professionally Inspired Design
- SatinGlide® Rack
- Stainless Steel Cooktop Trim
- EasyConvect™ Conversion System
- 10" Even-Heat Ultra Element
Cooktop Features:
- Cooktop Element Style: Radiant
- Left Front Element-Burner Type: Triple
- Left Rear Element-Burner Power: 700 W
- Left Rear Element-Burner Size: 6 inches
- Left Rear Element-Burner Type: Single
- Right Front Element – Burner Power: 3,200 W
- Right Front Element – Burner Size: 10 inches
- Right Front Element – Burner Type: Radiant Hyper
- Right Rear Element – Burner Power: 1,200 W
- Right Rear Element – Burner Size: 6 inches
- Right Rear Element – Burner Type: Single
- Cooktop Surface Color: Black
- Cooktop Surface Material: Ceramic Glass
- Number of Cooking Element-Burners: 5
- Center Rear Element – Burner Power: 100 W
- Center Rear Element – Burner Size: 6 inches
- Center Rear Element – Burner Type: Warming
- Left Front Element – Burner Power: 2700 W / 1950 W / 1050 W
- Left Front Element – Burner Size: 12 inches/ 9 inches / 6 inches
Configuration and Overview:
- Fuel Type: Electric
- Range Type: Freestanding Double Oven
- Size: 30 inches
- Capacity (Upper/Lower): 2.5/4.2 cu. ft.
Controls:
- Door Type: Metal and Glass
- Handle Material: Metal
- Selections: Bake, Broil, Control Lock, Cook Time, Delay Start, Easy Convect Conversion, Keep Warm Setting, Proofing, Sabbath Mode, Slow Cook
- UL: Yes
- Star K Compliant: Sabbath Mode
Oven Features:
- Automatic Convection Conversion Temperature Adjust: Yes
- Heating Element On Indicator Light: Yes
- Hot Surface Indicator Light: Yes
- Power On Indicator Light: Yes
- Bake Element Power: 2000 W (Both)
- Broiler Element Power: 3,600 W @ 240 V (Both)
- Broiler Location: Top of Oven
- Convection Element Power: 1,600 W
- Convection Element Type: Single – Fan
- Convection Functions: Bake, Broil, Roast
- Hidden Bake Element: Yes
- Light Type: Incandescent
- Number of Oven Lights: 1 Upper/ 1 Lower
- Number of Oven Racks: 1 Upper/ 2 Lower
- Number of Rack Guides: 2 Upper/ 5 Lower
- Oven Rack Type: 1 Gliding Roll-Out, 2 Heavy Duty
